Lextar
- 品牌介绍
-
UV LED Chip
● Wavelength 365~405nm
● Can use different types of PKG● High efficiency
● Environmentally safe – no mercuryModel Name Product Type Peak Wavelength
(nm)Dimension Forward Current
(mA)Radiant Flux
(mW)Forward Voltage
(V@350mA)CU09J Lateral UVA Chip 385/395/405 215 x 460 x 150 μm 20 20~30 3.1-3.5 CU22N 385 560 x 910 x 150 μm 120 150~210 3.2-3.6 CU45S 385 1150 x 1150 x 150 μm 350 typ. 390 3.2-3.6 CU45S 395/405 1150 x 1150 x 150 μm 350 typ. 420 3.2-3.6 CX45S High Power UVA Flip Chip 385/395/405 1150 x 1150 x 150 μm 700 typ. 920 3.3-3.8 CT15S High Power vertiacl UVA Chip 365 380 x 380 x 150 μm 150 175 3.2-3.6 385/395/405 380 x 380 x 150 μm 150 190 3.2-3.6 CT45S 365 1150 x 1150 x 150 μm 350 360 3.2-3.6 385/395/405 1150 x 1150 x 150 μm 350 480 3.2-3.6 -
IR Package
High Power IR Package PR88
-
IR Emitter
-
Health Monitor
High signal and low power comsuption, HRM monitor module and component
Bio Sensor for heath
Bio Sensor for health
HRM monitor module
| Lextar Electronics Corporation is a global leader in LED solutions with a strategic advantage of integrating upper streamepitaxial, middle stream chip, downstream package and various applications. Founded in May 2008, Lextar is a subsidiaryof AU Optronics, the leading TFT-LCD and solar PV manufacturer. With over 2,000 patents worldwide, Lextar is aninnovator of product applications, which include: Automotive LED, LCD backlights, luminaire, and various lighting solutions. Lextar currently has 2 manufacturing plants in Taiwan, and 3 in China. Lextar revenue reached US$427 million |
Products
UV/IR/Sensor
Lextar UV LED has high efficiency and competitive cost, which can be applied to various UV lighting products, such as nail lamp, photo-catalyst, bug zapper, plant grow lamp and ink curing.
UV
UV LED Modules
High Power UV LED Package
Low Power UV LED Package
